The XSONIC P79 Plastic Shoot Thru-Hull Transducer was designed for people that do not want to drill holes in the bottom of their boat, making it ideal for RIBS and racing sailboats. The in-hull transducer mounts inside the boat and will work on boats with deadrise up to 22 degrees. The 50/200khz Transducer is compatible with most Lowrance and Simrad display units.
The P79 in-hull transducer easily adjusts to hull deadrise angles up to 22 º. This ensures that the beam is vertically oriented to receive echos, resulting in accurate depth readings. Unlike traditional "puck" type transducers, the Airmar P79 consists of a base that is bonded to the hull and filled with liquid. The separate transducer then attaches to the base with a twist lock. The sound waves travel more efficiently though the liquid, giving the best possible performance.
Compatible with Simrad and Lowrance models with Black 9-Pin XSONIC Connector
Not Compatible with wood hulls, metal hulls or foam cored hulls.
Features:
- Compatible Hull material: single skin Fiberglass. Note not suitable for: aluminium, steel or wooden boats, sandwich foam Fiberglass hulls
- 600W Max Power
- 200/50 kHz Frequency
- 45°/12° Beam Width
- Depth only - no temp
- Easily adjusts to any Deadrise angle up to 22°
- Transmits sound waves directly at the bottom so strong echoes are reflected back to the transducer
- Can be removed in seconds for servicing or storage
- Only the base piece is bonded to the Hull. There is no adhesive layer under the Transducer face to absorb sound energy
- Simplifies In-Hull installation
